DS 3048 (Legacy product)
High availability dual controllers complement high density 4U 48-bay storage that is designed for powerful yet simple SMB and enterprise service in your SAN/DAS applications. Get more capacity and reliability in a dense system that delivers fast performance, convenient modular components, strong data integrity, friendly management, and extensive software bundles.
This model is discontinued; the recommended offering is EonStor DS SAN storage.
| Features | Benefits |
|---|---|
Up to 1.3M IOPS and 6,000 MBps throughput |
High IOPS ideal for database and VDI applications, while massive bandwidth enhances media editing and surveying jobs |
Dual controllers and redundant power supplies |
Fast failover performance and high data availability |
Up to 336 HDD support |
|
Hybrid host interface with optional onboard iSCSI |
Combine diverse connectivity environments on one system for greater utility |
Multiple host interface options |
Choose from up to 16Gb/s Fibre Channel, up to 10Gb/s iSCSI, or up to 12Gb/s SAS based on your needs and budget |
SSD cache and tiering solutions |
|
Intelligent Drive Recovery (IDR) |
Smarter media scan and effortless drive clone and replace |
Secure remote replication |
The backup to offsite locations provides very reliable and safe disaster recovery |
SED compatible |
Virtually unbreakable hardware encryption |
Tiered event messages |
Clear and easily actionable system notifications keep you informed and in control |
Thin provisioning |
Improve storage utilization up to 80% - get more for your investment |
Multi-target snapshot |
With up to 4096 targets, always have backups to recover vital data at different points in time |
Multi-pair volume copy/mirror |
Up to 64 pairs ensure entire volumes can be backed up with minimal effort as data grows |
SANWatch 3.0 interface |
User friendly browser-based deployment and management |
Intelligent drive spin-down and 80 PLUS power supplies |
Lower costs through reduced power draw and longer drive lifespan |
High Density |
Accommodates 48 drives in a single 4U chassis with a convenient 3-drawer design |
Super capacitor backup with flash module |
Deliver power and securely save cached data to flash modules during electric grid outages |
Host Ports
- Onboard host ports:
- 1GbE (RJ-45) x 4
- Host board options:
- 16Gb/s FC x 4
- 8Gb/s FC x 8
- 1GbE (RJ-45) x 8
- 10GbE (SFP+/RJ-45) x 4
- 10GbE (RJ-45) x 2
- 6Gb/s SAS x 4
- 12Gb/s SAS x 4
Controller
Dual redundant
Cache Memory
Default DDR3 4GB, up to 32GB
Drive Connectivity
- 6Gb/s SAS connectivity
- S.M.A.R.T. support
- Automatic bad-sector reassignment
- Dedicated bandwidth to each connected drive
Supported Drives
3.5" 6Gb/s NL-SAS 7,200 RPM HDD
Max. Drive Number
- Per system: 48
- Via expansion enclosures: 336
Rack Support
4U, 19-inch rackmount
RAID Functionality
- Global, designated or enclosure hot-spare
- RAID levels supported : RAID 0, 1, 3, 5, 6, 10, 30, 50, 60
- Online expansion by:
- Adding new drives
- Copying and replacing drives with drives of larger capacity
- RAID migration
- Configurable stripe size and write policy per system
- Intelligent drive handling
- In degraded mode: skips irreparable blocks to continue rebuild
- In normal operation: data-block verification and repair
Data Services
- Default software features include:
- Thin provisioning
- Snapshot: 64 per source partition, 128 per system
- Local replication (block level): 4 per source volume, 16 per system
- Optional software features require additional license:
- SSD cache
- Automated storage tiering: 4 tiers per pool
- Advanced snapshot: 256 per source partition, 4,096 per system
- Advanced local replication (block level): 8 per source volume, 256 per system
- Advanced remote replication (block level): 8 per source volume, 64 per system
Green Design
- High-efficiency power supplies
- Intelligent multi-level drive spin-down
Availability and Reliability
- Redundant, hot-swappable hardware modules
- Device mapper
- Trunk group
- Cache safe technology
- UPS
Notification
Various event notification methods including email and SNMP trap.
Management
- Web-based SANWatch management software
- Embedded RAIDWatch
- Terminal via RS-232C
- Telnet and SSH
- LCD keypad panel
Supported OS
- Microsoft Windows Server
- Red Hat Enterprise Linux
- SUSE Linux Enterprise
- Sun Solaris
- macOS X
- VMware
- Citrix XenServer
- OpenStack Cinder
Service and Support
Standard service
- 3-year limited hardware/software warranty and 8x5 phone, web, and email support
Upgrade/Extension service (optional and service may vary by region)
- replacement part dispatch on the next business day (up to 5 years)
Power
- Power supplies: 530W x 3
- AC voltage: 100VAC @10A to 240VAC @5A with PFC (auto-switching)
- Frequency: 47-63 Hz
Environmental
- Temperature:
- Operating: 0°C to 35°C
- Non-operating: -40°C to 60°C
- Altitude:
- Operating: sea level to 3,660 m (12,000 ft)
- Non-operating: sea level to 12,192 m (40,000 ft)
- Relative humidity: 5% to 95% non-condensing, operating and non-operating
Safety Standards
- Safety: UL, BSMI, CB, EAC
- Electromagnetic compatibility: CE, BSMI, FCC, KC
Dimensions (W x H x D)
446 x 176 x 874 mm (without chassis ears and protrusions)
Weight (without HDDs)
150.80 lbs (68.4 kg)
Package Dimensions (W x H x D)
With paper pallet: 630 x 426 x 1,150 mm
With HDD packages: 630 x 670 x 1,150 mm
